otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput > Class Template Reference

computes the LAI from reflectances More...

#include <otbVegetationIndicesFunctor.h>

+ Inheritance diagram for otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >:
+ Collaboration diagram for otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >:

Public Types

typedef
itk::VariableLengthVector
< TInput1 >
InputVectorType

typedef NDVI< TInput1, TInput2,
TOutput >
NDVIFunctorType


Public Member Functions

 LAIFromReflectancesLinear ()

virtual ~LAIFromReflectancesLinear ()

unsigned int GetIndex (BandName::BandName band) const

virtual std::string GetName () const

double GetNirCoef (void) const

unsigned int GetNIRIndex () const
 Get NIR Index. More...

double GetRedCoef (void) const

unsigned int GetRedIndex () const
 Get Red Index. More...

NDVIFunctorType GetReflectances (void) const

bool operator!= (const RAndNIRIndexBase &) const

TOutput operator() (const InputVectorType &inputVector) const

TOutput operator() (const TInput1 &r, const TInput2 &nir) const

bool operator== (const RAndNIRIndexBase &other) const

void SetIndex (BandName::BandName band, unsigned int channel)

void SetNirCoef (const double val)

void SetNIRIndex (unsigned int channel)
 Set NIR Index. More...

void SetRedCoef (const double val)

void SetRedIndex (unsigned int channel)
 Set Red Index. More...


Protected Member Functions

TOutput Evaluate (const TInput1 &r, const TInput2 &nir) const


Protected Attributes

double m_EpsilonToBeConsideredAsZero


Private Attributes

NDVIFunctorType m_NDVIfunctor

double m_NirCoef

double m_RedCoef


Detailed Description

template<class TInput1, class TInput2, class TOutput>
class otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >

computes the LAI from reflectances

This functor computes the LAI from reflectances using a linear relationship. $ LAI = \beta_0 + \sum_j \beta_j \rho_j $ where $ \rho $ are the reflectances Default values for the parameters are taken from A. Bsaibes et al. / Remote Sensing of Environment 113 (2009) 716-729

Definition at line 1351 of file otbVegetationIndicesFunctor.h.

Member Typedef Documentation

template<class TInput1, class TInput2, class TOutput>
typedef itk::VariableLengthVector<TInput1> otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::InputVectorType
inherited

Vector pixel type used to support both vector images and multiple input images

Definition at line 49 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
typedef NDVI<TInput1, TInput2, TOutput> otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::NDVIFunctorType

Definition at line 1360 of file otbVegetationIndicesFunctor.h.

Constructor & Destructor Documentation

template<class TInput1 , class TInput2 , class TOutput >
otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::LAIFromReflectancesLinear ( )
inline

Definition at line 1361 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
virtual otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::~LAIFromReflectancesLinear ( )
inlinevirtual

Definition at line 1362 of file otbVegetationIndicesFunctor.h.

Member Function Documentation

template<class TInput1 , class TInput2 , class TOutput >
TOutput otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::Evaluate ( const TInput1 &  r,
const TInput2 &  nir
) const
inlineprotectedvirtual
template<class TInput1, class TInput2, class TOutput>
unsigned int otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::GetIndex ( BandName::BandName  band) const
inlineinherited

Get index, generic method

Definition at line 91 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
virtual std::string otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::GetName ( ) const
inlinevirtual

Return the index name

Implements otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >.

Definition at line 1355 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
double otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::GetNirCoef ( void  ) const
inline
template<class TInput1, class TInput2, class TOutput>
unsigned int otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::GetNIRIndex ( ) const
inlineinherited

Get NIR Index.

Definition at line 119 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
double otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::GetRedCoef ( void  ) const
inline
template<class TInput1, class TInput2, class TOutput>
unsigned int otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::GetRedIndex ( ) const
inlineinherited

Get Red Index.

Definition at line 109 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
NDVIFunctorType otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::GetReflectances ( void  ) const
inline
template<class TInput1, class TInput2, class TOutput>
bool otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::operator!= ( const RAndNIRIndexBase< TInput1, TInput2, TOutput > &  ) const
inlineinherited

Definition at line 52 of file otbVegetationIndicesFunctor.h.

template<class TInput1, class TInput2, class TOutput>
TOutput otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::operator() ( const InputVectorType inputVector) const
inlineinherited

Definition at line 63 of file otbVegetationIndicesFunctor.h.

template<class TInput1, class TInput2, class TOutput>
TOutput otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::operator() ( const TInput1 &  r,
const TInput2 &  nir
) const
inlineinherited

Definition at line 69 of file otbVegetationIndicesFunctor.h.

template<class TInput1, class TInput2, class TOutput>
bool otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::operator== ( const RAndNIRIndexBase< TInput1, TInput2, TOutput > &  other) const
inlineinherited

Definition at line 57 of file otbVegetationIndicesFunctor.h.

template<class TInput1, class TInput2, class TOutput>
void otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::SetIndex ( BandName::BandName  band,
unsigned int  channel
)
inlineinherited

Set index, generic method

Definition at line 79 of file otbVegetationIndicesFunctor.h.

template<class TInput1 , class TInput2 , class TOutput >
void otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::SetNirCoef ( const double  val)
inline
template<class TInput1, class TInput2, class TOutput>
void otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::SetNIRIndex ( unsigned int  channel)
inlineinherited
template<class TInput1 , class TInput2 , class TOutput >
void otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::SetRedCoef ( const double  val)
inline
template<class TInput1, class TInput2, class TOutput>
void otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::SetRedIndex ( unsigned int  channel)
inlineinherited

Member Data Documentation

template<class TInput1, class TInput2, class TOutput>
double otb::Functor::RAndNIRIndexBase< TInput1, TInput2, TOutput >::m_EpsilonToBeConsideredAsZero
protectedinherited
template<class TInput1 , class TInput2 , class TOutput >
NDVIFunctorType otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::m_NDVIfunctor
private
template<class TInput1 , class TInput2 , class TOutput >
double otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::m_NirCoef
private
template<class TInput1 , class TInput2 , class TOutput >
double otb::Functor::LAIFromReflectancesLinear< TInput1, TInput2, TOutput >::m_RedCoef
private

The documentation for this class was generated from the following file:
