otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage > Class Template Reference

#include <otbRealAndImaginaryImageToComplexImageFilter.h>

Inheritance diagram for otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >:

Collaboration diagram for otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >:

Public Types
typedef itk::SmartPointer< const Self >	ConstPointer
typedef TInputImageImaginaryPart::PixelType	InputImaginaryPartPixelType
typedef TInputImageRealPart::PixelType	InputRealPartPixelType
typedef TOutputImage::PixelType	OutputPixelType
typedef itk::NumericTraits< OutputPixelType >::ValueType	OutputPixelValueType
typedef itk::SmartPointer< Self >	Pointer
typedef RealAndImaginaryImageToComplexImageFilter	Self
typedef itk::BinaryFunctorImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage, Function::RealAndImaginaryToComplex< typename TInputImageRealPart::PixelType, typename TInputImageImaginaryPart::PixelType, typename TOutputImage::PixelType > >	Superclass

Public Member Functions
virtual ::itk::LightObject::Pointer	CreateAnother (void) const
virtual const char *	GetNameOfClass () const
void	SetInputImaginaryPart (const TInputImageImaginaryPart *imageImaginaryPart)
void	SetInputRealPart (const TInputImageRealPart *imageRealPart)

Static Public Member Functions
static Pointer	New ()

Protected Member Functions
	RealAndImaginaryImageToComplexImageFilter ()
	~RealAndImaginaryImageToComplexImageFilter () override

Private Member Functions
void	operator= (const Self &)=delete
	RealAndImaginaryImageToComplexImageFilter (const Self &)=delete

Detailed Description

template<class TInputImageRealPart, class TInputImageImaginaryPart, class TOutputImage>
class otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >

Computes pixel-wise the complex image of a real and imaginary image.

See also

RealAndImaginaryImageToComplexImageFilter

Definition at line 70 of file otbRealAndImaginaryImageToComplexImageFilter.h.

Member Typedef Documentation

ConstPointer

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef itk::SmartPointer<const Self> otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::ConstPointer

Definition at line 83 of file otbRealAndImaginaryImageToComplexImageFilter.h.

InputImaginaryPartPixelType

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef TInputImageImaginaryPart::PixelType otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::InputImaginaryPartPixelType

Definition at line 92 of file otbRealAndImaginaryImageToComplexImageFilter.h.

InputRealPartPixelType

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef TInputImageRealPart::PixelType otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::InputRealPartPixelType

Definition at line 89 of file otbRealAndImaginaryImageToComplexImageFilter.h.

OutputPixelType

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef TOutputImage::PixelType otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::OutputPixelType

Definition at line 93 of file otbRealAndImaginaryImageToComplexImageFilter.h.

OutputPixelValueType

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef itk::NumericTraits<OutputPixelType>::ValueType otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::OutputPixelValueType

Definition at line 94 of file otbRealAndImaginaryImageToComplexImageFilter.h.

Pointer

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef itk::SmartPointer<Self> otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::Pointer

Definition at line 82 of file otbRealAndImaginaryImageToComplexImageFilter.h.

Self

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef RealAndImaginaryImageToComplexImageFilter otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::Self

Standard class typedefs.

Definition at line 77 of file otbRealAndImaginaryImageToComplexImageFilter.h.

Superclass

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

typedef itk::BinaryFunctorImageFilter<TInputImageRealPart, TInputImageImaginaryPart, TOutputImage, Function::RealAndImaginaryToComplex<typename TInputImageRealPart::PixelType, typename TInputImageImaginaryPart::PixelType, typename TOutputImage::PixelType> > otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::Superclass

Definition at line 81 of file otbRealAndImaginaryImageToComplexImageFilter.h.

Constructor & Destructor Documentation

RealAndImaginaryImageToComplexImageFilter() [1/2]

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::RealAndImaginaryImageToComplexImageFilter ( )

inlineprotected

Definition at line 117 of file otbRealAndImaginaryImageToComplexImageFilter.h.

~RealAndImaginaryImageToComplexImageFilter()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::~RealAndImaginaryImageToComplexImageFilter ( )

inlineoverrideprotected

Definition at line 120 of file otbRealAndImaginaryImageToComplexImageFilter.h.

RealAndImaginaryImageToComplexImageFilter() [2/2]

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::RealAndImaginaryImageToComplexImageFilter ( const Self &  )

privatedelete

Member Function Documentation

CreateAnother()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

virtual::itk::LightObject::Pointer otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::CreateAnother

(

void

)

const

GetNameOfClass()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

virtual const char* otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::GetNameOfClass ( ) const

virtual

Runtime information support.

New()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

static Pointer otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::New ( )

static

Method for creation through the object factory.

operator=()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

void otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::operator= ( const Self &  )

privatedelete

SetInputImaginaryPart()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

void otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::SetInputImaginaryPart ( const TInputImageImaginaryPart *  imageImaginaryPart )

inline

Definition at line 111 of file otbRealAndImaginaryImageToComplexImageFilter.h.

SetInputRealPart()

template<class TInputImageRealPart , class TInputImageImaginaryPart , class TOutputImage >

void otb::RealAndImaginaryImageToComplexImageFilter< TInputImageRealPart, TInputImageImaginaryPart, TOutputImage >::SetInputRealPart ( const TInputImageRealPart *  imageRealPart )

inline

Begin concept checking End concept checking

Definition at line 106 of file otbRealAndImaginaryImageToComplexImageFilter.h.

---

The documentation for this class was generated from the following file:

• otbRealAndImaginaryImageToComplexImageFilter.h
